Reliable, fanless rail computer with multiple I/O capabilities. A rugged construction combined with a wide temperature range, shock and vibration resistance and a compact form factor provides a powerful platform for rail, vehicle and trackside applications.
The low power Intel® Atom™ processor keeps upfront and through-life costs to a minimum. The processor is optimised for energy efficiency, ensuring low thermal output and meaning the RCE-210/211/212 can be specified with minimal impact on install location. Integrated Intel® HD graphics equip the platform to deal with demanding graphics applications.
The 9 – 28V DC input power provisions for fluctuating power sources, achieving compatibility with a broader variety of applications and larger equipment installations.
The RCE-210/211/212 features a rugged fanless design, combining excellent thermal performance with low weight. The system operates with no moving parts, ensuring silent operation and improving ease of maintenance to support high-reliability.
The RCE-210/211/212 is certified to EN50155 and EN50121, making it ideal for in-vehicle and rail environments.
Customisable expansion with multiple SIM and mini-PCIe slots ensures the RCE-210/211/212 will meet your exact requirements.
The RCE-200/201 has an operating temperature range of -25°C to 70°C, providing extended operational life in applications with challenging temperature demands.
| CPU | Atom E3845 Quad Core, 1.9GHz |
| Memory | 2GB DDR3, expandable to 8GB |
| Storage | 1 x 2.5” SATA SSD/HDD, 1 x mSA |
| Graphics | On board HD graphics |
| Expansion | 3 x Mini-PCIe sockets (including mSATA), 1 x SIM socket |
| LAN | 2 x Gigabit LAN by Intel® 82574L Port |
| I/O | 2 x RS232, 4 x RS232/422/485 |
| Optional I/O | Isolation for 2 x RS232/422/485 ports |
| Power Input | 9V to 28V, DC-in |
| Watchdog Timer | Reset: 1 to 255 sec./min. per step |
| Smart Management | Wake on LAN, PXE supported |
| HW Monitor | Monitoring temperature, voltages |
| GPS | Onboard GPS Module (Optional) |
| Video / Audio | 2 x HDMI, 1 x VGA, optional LVDS / 1 x Mic in, 1 x Line out |
| Operating System | Windows 7/8/10, Linux |
| PSU | Optional 60W AC Power Adapter |
| Mounting | Wallmount by mounting bracket |
| Dimensions | 257mm (W) x 48mm (H) x 141mm (D) |
| Weight | 2.1kg |
| Construction | Aluminium |
| Operating Temperature | -25°C to 70°C (SSD) |
| Storage Temperature | -40°C to 85°C |
| Shock / Vibration | 50g, 11ms / 5g, 5-500Hz |
| Certification | CE, FCC, EN50155, EN50121 |
| Ordering Information | RCE-210: Atom E3845 quad core, 2 isolated serial ports |
